Model 570 - Pressure Transmitter

The Viatran model 570 is a durable high pressure range product meant for use in situations requiring prior approvals for transmitter use. It gives an output of 4-20 mA for ranges of 0-100 through 0-100 000 PSI. It is sealed and thus provides reliable performances even in harsh production environments and even those rated hazardous.


The Viatran model 570 pressure transmitter has many high-rated features making it a product of choice in its class, including:

  • An IP-68 rating
  • The ShuntCal feature
  • Ideal for applications involving high pressures
  • RapidShip facility which ensures a two-day turnaround on orders
  • Availability of several optional accessories to fit it for different applications
  • Construction material is all-stainless steel

The use of welding to bond parts and components together, with the stainless steel material, enable the use of Model 570 in test or industrial applications which expose it to corrosive media or gases. This includes the use of an O-ring free sealing design, boosting its durability in such environments. These units are labeled and approved to FM standards, and comply with NEC/API Dual Seal requirements. Wetted parts made of 316 stainless steel, Inconel or Hastalloy may be ordered in accordance with client requirements and to suit the most harsh applications.

Operating and Other Relevant Parameters

The performance of Model 570 is shown in the following table:

. .
Full Scale Pressure Range 0-100 thru 0-100 K PSIS (0-6.89 thru 0-6894 bar)
Linearity (Best Fit Straight Line) 0-100 PSI (0-6.89 bar) ±0.5%
150-10 K PSI (10.3-6.89 bar) ±0.2%
15 K-100 K PSI (1034-6894 bar) ±0.25%
Hysteresis ≤0.15% FSO
Repeatability ≤0.15% FSO
Full Scale Output (FSO) 16 mA
Zero and Span Balance ±1% FSO
Long Term Stability ≤±0.25% FSO per 6 months
Response Time <2 mSec to reach 90% FSO
Temperature Effect on Zero ≤±1% FSO per 100 °F (37 °C)
Temperature Effect on Span ≤±1% FSO per 100 °F (37 °C)
Compensated Temperature 70 °F to 170 °F (21 °C to 76 °C)
Operating Temperature -40 °F to 190 °F (-40 °C to 87 °C)
Storage Temperature Limit -65 °F to 250 °F (-53 °C to 121 °C)


The electrical parameters are summarized below:

. .
Supply Voltage 12 to 30 Vdc
Power Supply Regulation Effect ≤±0.02% FSO per Volt
Output Signal 4 - 20 mA
Bridge Impedance 5000 Ohms nominal
Circuit Protection Varistor protected across the input leads for surges above 40 V and currents to 250 Amps peak with a pulse width of 20 μSecs. Reverse polarity protected.
Insulation Resistance >200 MegOhms to case ground
Electrical Connection 1/2" NPT (M), 18 AWG wire, 72"
Wire Color Codes
Red +Power/Signal
Black -Power/Signal
Green Case ground
White No Connection


The mechanical properties of the 570 are displayed in the following table:

. .
Pressure Connection 0-50 thru 0-15 K PSI 1/4" - 18 NPT Female (0-3.3 thru 0-1034 bar)
0-20 K thru 0-50 K PSI 1/4" F250-C High Pressure Tube (0-1378 thru 0-3447 bar)
0-60 K thru 0-100 K PSI 5/16" F312C High Pressure Tube (0-4136) thru 0-6894 bar)
Proof Pressure 0-100 thru 0-15 K PSI 1.5 times FSPR or 20K PSI (1378 bar), (0-6.8 thru 0-1034 bar) whichever is less
0-20 K thru 0-100 K PSI 1.2 times FSP (0-1378 thru 0-6894 bar)
Burst Pressure 0-100 thru 0-15 K PSI ≥ 2.3 to 5 times FSPR dependent on (0-6.8 thru 0-10342 bar) sensor
0-20K thru 0-100 K PSI 1.5 times FSPR or 125 K PSI (8618 bar) (0-1378 thru 0-6894 bar) whichever is less
Mounting Supported by process piping or optional mounting bracket


The 570 is constructed from the following materials:

. .
Enclosure 0-100 thru 0-15 K PSI 15-5 PH and 316 stainless steel (0-6.8 thru 0-1034 bar)
0-20 K thru 0-100 K PSI 316 SST and PH 13-8 Mo SST (0-1378 thru 0-6894 bar)
Wetted Parts 0-100 thru 0-15 K PSI 15-5 PH stainless steel (0-6.8 thru 0-1034 bar)
0-20 K thru 0-100 K PSI PH 13-8 Mo SST (0-1378 thru 0-6904 bar)
Shock Limitation 100 G’s
Weight 24 oz. (0.680 kilograms)
Identification Laser etched onto body
Enclosure Classification NEMA 4X


Various optional parts and components are available as per customer requirement, and are detailed in the following table:

. .
DF Bleed port (10 K PSI and below)
DG Improved temperature compensation (<5%/100 °F for zero/span)
DH Special range
DQ Cleaning for oxygen service
EA Special calibration run
JJ Direct mount indicator with explosion proof housing
JS Direct mount indicator
ME CSA explosion proof label
MR Modified electrical damping
NG ATEX flameproof label
NH Customer specified identification
NJ CE label
NK ATEX intrinsic safety label
NX CSA intrinsic safety label
NY FM explosion proof label
NZ FM nonincendive label
PW 1/8 DIN digital indicator (consult factory)
QA 316 stainless steel wetted parts
QB Inconel (X-750) wetted parts
QC Hastelloy (C-276) wetted parts
TF FM intrinsic safety label
TW GOST certification label
Y ( ) Alternate pressure ports


It should be noted that applying some of these options to the 570 may impact standard performance. For more information, please contact the Viatran representative.
