Nov 7 2014
Texas Instruments (TI) today announced a new series of MSP430™ industrial microcontrollers (MCUs) integrated with smart analog for high accuracy, precision and cost savings. The MSP430i204x MCUs meet the broad temperature range requirements from –40 to 105 degrees Celsius needed for industrial and smart grid applications.
Texas Instruments today announced a new series of MSP430 industrial microcontrollers integrated with smart analog for high accuracy, precision and cost savings.
The new MSP430 i-series MCUs are ideal for a variety of cost-sensitive industrial segments including occupancy sensors, remote temperature and pressure transmitters, power monitoring, and many more.
The new MSP430i204x industrial MCUs contain integrated smart analog, including up to four integrated sigma delta analog-to-digital converters (ADCs) that provide accuracy and precision down to 1 percent in smart metering products across a 2000:1 dynamic range. The MSP430i204x MCUs also include an internal digitally controlled oscillator (DCO) that eliminates the need for an external crystal. Small package sizes enable designers to reduce board space and lower system costs, while increasing accuracy.
Developers porting to the new MSP430i204x industrial MCUs can scale their designs to include 16 or 32 KB flash memory and integrated analog such as sigma-delta analog front ends (AFEs). Texas Instruments also offers three comprehensive TI Designs with schematics, block diagrams, bill of material (BOM), design files and test reports to help developers start their embedded server power metering and smart power strip designs. These complete industrial reference designs incorporate TI's complementary TPS54060 step-down (buck) converter. In addition, developers can leverage TI's SimpleLink™ Wi-Fi CC3200 wireless MCU to enable industrial designs to communicate with other connected devices or TI's DAC8760 family of digital-to-analog converters (DACs) for 4-20mA current loop industrial sensor applications to further reduce board space and lower system costs, while maintaining high accuracy in their designs.
Features and benefits of TI's industrial MCU portfolio
- MSP430i204x devices provide 1 percent accuracy across a 2000:1 dynamic range through -40 degrees to +105 degrees Celsius.
- Available in small package sizes, 28-pin TSSOP and 32-pin QFP, enabling developers to reduce design cost and create smaller products for industrial applications.
- Simultaneous sampling of the on-chip 24-bit Sigma Delta ADCs eliminates software compensation for sequential sampling, which helps developers reduce the size of software code.
- Additional analog provides tamper detection for metering, which allows developers to design smart energy meters that can detect unauthorized access.
- Free Energy Library code performs all of the energy and power calculations required for ANSI/IEC qualified meters and provides an easy starting point for customers developing utility meter products.
