Hydrogen, a green and efficient energy source, is widely used in electronics, automotive, and aerospace sectors. But its potential is tempered by its flammability and difficulty of detection, since it is both colorless and odorless.
This has spurred the development of highly sensitive hydrogen sensors with rapid response times and reliability. Current efforts are focused on structural design and material innovation, as well as developing resistive and capacitive optical systems.1
A recent study in the International Journal of Hydrogen Energy describes a novel resistive chemical-mechanical hydrogen sensor developed using microelectromechanical system (MEMS) technology.
The device incorporated a composite piezoresistor made from silver nanowires and polyimide, paired with a palladium-coated microcantilever. The design, optimized through theoretical modeling and simulation, demonstrated ultra-high sensitivity levels of 2825 to 47083 at hydrogen concentrations from 0.4 % to 2.0 %.
The performance was attributed to combined surface and bulk resistance effects. In addition to its high sensitivity, the sensor exhibited strong stability, an encouraging sign for its use in hydrogen monitoring outside of the lab.1
Download your PDF now!
Novel Anisotropic Piezoelectric Sensors
Flexible piezoelectric sensors convert mechanical energy into electrical signals without external power. They can be made from a range of materials, but traditional designs often struggle with directional sensing and the detection of microscale deformations.
Research typically improves sensitivity by enhancing the piezoelectric coefficients or mechanical transmission efficiency, but vector sensing remains limited by material constraints.2
A new approach involves the use of anisotropic architectures, mimicking crystal asymmetry. Fiber-shaped piezoelectric materials have distinct longitudinal and radial responses, which allow directional perception. A study in Nano-Micro Letters made use of this principle to develop ultra-sensitive anisotropic piezoelectric sensors made from fully oriented filaments.
Using lead zirconate titanate-glass fiber (PST-EGF) composites prepared via sol-gel immersion, they created thin films with fixed orientation, stabilized by polyvinylidenene fluoride (PVDF).2
The team's sensors achieved micrometer level resolution of deformation, with porous ferroelectrets and multilayer PZT structures to ensure efficient load transfer. They successfully provided vector sensing capability by decoupling vibration magnitude and direction. In fact, wrinkes as small as five micrometers and strains as low as 0.06 % were detectable. Coupled with machine learning, the sensors identified 10 different surface textures with perfect accuracy, suggesting strong potential for tactile robotics and aerospace monitoring.
Image Credit: Kwangmoozaa/Shutterstock.com
Biological Receptor-inspired Mechanical Sensors
Wearable technologies are experiencing a boom across industries. For them to perform, they require sensors that are flexible, stable, and capable of selective detection under complicated conditions. However, many designs falter when capturing weak physiological signals, lack spatial resolution, or suffer from signal interference.
Bioinspired approaches may offer a way forward.
Image Credit: thaworn chaiyarat/Shutterstock.com
A recent innovation takes inspiration from scorpions, whose slit receptors naturally combine stress concentration, high-pass filtering, and omnidirectional localization. Published in Advanced Bionics, the researchers applied these mechanisms to flexible, crack-based structures, producing exceptionally sensitive sensors.3
The design includes gradient-crack patterns for heightened responsiveness, viscoelastic materials for signal decoupling, and curvilinear arrays for accurate localization. A vertically stacked heterogeneous integration strategy further supports multimodal sensing, enabling devices to simultaneously track pressure, temperature, and multiaxial stress.
The system's bionic stretchable conductive film and strain-isolated communication interfaces demonstrate strong potential across various uses.3
In medical monitoring, the sensor’s ultra-high sensitivity and sub-nanometer signal capture could enable precise detection of weak physiological signals such as Parkinson’s tremors and cardiovascular impulses, contributing to the development of next-generation non-invasive wearable devices.
In the Industrial Internet of Things, the sensor’s multimodal capabilities and omnidirectional sensing can allow for real-time monitoring of micron-level contact forces during precision robotic assembly, supporting enhanced tactile feedback systems.
In more extreme environments, such as lunar rover terrain sensing and deep-sea exploration, the system’s viscoelastic high-pass filtering and anti-fatigue design could enable continuous monitoring of stress corrosion and other harsh conditions.3
Magnetic Crack-based Piezoinductive Mechanical Sensors
Soft mechanical sensors are essential for robotics and human-machine interfaces, but balancing high sensitivity, robust performance, and reproducibility has proven difficult in research.
Piezoresistive and piezocapacitive devices offer simplicity here as soft mechanical sensors, although they face difficulty in strain sensitivity and reliability. New strategies are needed.4
A study published in Nature Communications proposed a magnetic crack-based piezoinductive sensor (MC-PIS). This device uses strain-induced changes in magnetic flux across cracked ferrite films. An underlying coil measures inductance variations, combining with flux changes to provide bidirectional, ultrasensitive mechanical sensing.
Unlike conventional sensors, the sensor showed consistent performance in tests, even when scratched in half or run over by a car, demonstrating exceptional durability and insensitivity to environmental factors like temperature, humidity, and dust.4
The MC-PIS achieved a 0.01 ° precision (equivalent to 0.8 µε strain) across a broad range from -200 ° (compression) to 327 ° (tension). This was enabled by a gradual decrease in magnetic reluctance through through-thickness cracks between ferromagnetic flakes. The structure allowed fast data acquisition, excellent reproducibility, and no fatigue-related degradation.4
In practical demonstrations, 16 MC-PIS units were integrated into a flexible ribbon for real-time dynamic shape monitoring, and a soft artificial finger with the MC-PISs was made, able to recognize delicate surface topology and distinguish musical notes through vibration. It was also used in a soft crawling robot that responded to external attacks and in a soft gripper that performed tasks for planting a small tree.4
The system’s strengths make it suitable for industrial environments, although performance could be affected by strong magnetic fields or nearby metal objects, if they alter the relative permeability/induce eddy currents. Overall, the MC-PIS presented a novel approach for high durability and sensitivity sensors in robotics and automation applications.4
Conclusion
These recent advances in mechanical sensors have resulted in unprecedented sensitivity, enabling the detection of subtle forces, vibrations, and chemical signals. From anisotropic piezoelectric materials to bioinspired crack-based architectures, innovations are extending the abilities of sensors further into healthcare, robotics, and industrial applications.
Read more about the latest in sensor technology here!
References and Further Reading
- Li, H. et al. (2021). Ultra-high sensitive micro-chemo-mechanical hydrogen sensor integrated by palladium-based driver and high-performance piezoresistor. International Journal of Hydrogen Energy, 46(1), 1434-1445. DOI: 10.1016/j.ijhydene.2020.10.013, https://www.sciencedirect.com/science/article/abs/pii/S0360319920337769
- Yin, H. et al. Ultra-High Sensitivity Anisotropic Piezoelectric Sensors for Structural Health Monitoring and Robotic Perception. Nano-Micro Letters, 17, 42 (2025). DOI:10.1007/s40820-024-01539-6, https://link.springer.com/article/10.1007/s40820-024-01539-6
- Wang, C., Tian, M., Ding, Y., Han, Z., Ren, L. (2025). High-performance mechanical sensors inspired by the slit perception structure of biological receptors. Advanced Bionics, 1(2-3), 113-123. DOI:10.1016/j.abs.2025.06.002, https://www.sciencedirect.com/science/article/pii/S2950387625000066
- Peng, Y. et al. (2025). Magnetic crack-based piezoinductive mechanical sensors: Way to extreme robustness and ultra-sensitivity. Nature Communications, 16(1), 1-10. DOI: 10.1038/s41467-025-61784-0, https://www.nature.com/articles/s41467-025-61784-0
