As pollution continues to rise globally, the ability to quickly and reliably assess water quality has never been more important. But most conventional testing systems rely on large, expensive equipment, which limits their use, especially in remote areas or low-resource settings.
That’s where ECL comes into play. It’s a sensitive and highly adaptable technique that’s gaining attention in both research and diagnostic fields. What sets it apart is that it doesn’t need an external light source: luminescence is triggered electrochemically. This leads to low background noise, high sensitivity, and precise control over where and when light is emitted.
One of ECL’s biggest strengths is that it doesn’t require a complicated setup. A typical system includes a potentiostat, an electrochemical cell, a light detector, and a dark box. Because of this minimal hardware requirement, ECL is well-suited for integration into smaller, portable devices, especially when combined with microfluidic platforms.
These compact systems can analyze small sample volumes with high sensitivity and reproducibility. They also require less hands-on preparation and are easier to use outside the lab. But despite progress in the field, designing low-cost, portable systems that remain both accurate and user-friendly is still a major challenge and an active area of research.
A Self-Powered ECL Solution
In this study, the team developed and optimized a microfluidic ECL device that can detect amines in flowing liquids without needing external electricity or a potentiostat. Instead, the system runs on streaming potential, a voltage that’s generated when an electrolyte flows through a microchannel with charged surfaces.
As the liquid moves under pressure, it creates a streaming potential of around 2–3 volts. That’s enough to drive the redox reactions needed to trigger ECL without any battery or wired power source.
The researchers tested different variables to improve performance, including the type of channel-filling material, the composition of the solvent, and the flow rate. Once optimized, the device was used to detect amines (chemicals that are not only common industrial pollutants but also act as useful co-reactants in ECL reactions).
To show how the device works in practice, the team coated the electrode surface with an organic chromophore. When a solution containing amines was passed through the system, it triggered light emission via ECL, clearly indicating the presence of these pollutants.
How the Device Works
The key to the device is its ability to turn liquid movement into usable energy. It captures the natural voltage produced as the fluid flows, then uses that energy to power a chemical reaction that produces light.
The process involves two main ingredients:
- A coreactant, which undergoes a sacrificial oxidation reaction, and
- A chromophore, which gets excited and emits light as it returns to its ground state
The light signal acts as a clear, real-time indicator of whether a target compound—like an amine—is present in the sample.
What’s most notable is that this entire process doesn’t require any external power. The researchers built a simple microfluidic system with two chambers containing platinum wire electrodes, connected by a porous material-filled channel. The electrodes are linked by an ammeter to create a bipolar electrode system. Even pushing liquid through the channel manually with something as simple as a syringe was enough to generate the voltage needed to drive the reaction.
In their experiments, the researchers used benzothiadiazole-triphenylamine (BTD-TPA) as the chromophore and tri-n-propylamine (TPrA) as the coreactant. When a TPrA solution flowed through the system, the redox reactions at the anode produced visible light—confirming successful detection.
From Lab Bench to Real-World Use
This is more than just a cool lab experiment. The device showed consistent results with minimal sample prep. It detected TPrA in both distilled and tap water down to concentrations as low as 0.01 mM—without the need for any fancy buffers or electrolytes.
The team also tested other common amines, such as 2-(dibutylamino)ethanol and triethanolamine, and saw similar results, though with slightly lower sensitivity. Still, the system worked reliably, even when powered by something as simple as pushing water through it with a syringe.
The system also proved easy to operate, requiring nothing more than a simple syringe to generate flow. This simplicity makes it especially well-suited for field applications, where access to electricity or complex lab setups may be limited or unavailable.
Looking Ahead
This prototype points to a promising future for portable, affordable water testing devices, especially those that can generate their own power from the environment. The idea that you could use the natural flow of water, in a river or pipeline, to drive chemical detection without any external power is a compelling one.
As the technology continues to improve, these types of systems could support long-term environmental monitoring in places where traditional setups simply aren’t practical.
Journal Reference
Suzuki, R. et al. (2025). An electrochemiluminescence device powered by streaming potential for the detection of amines in flowing solution. Nature Communications, 16(1), 1-11. DOI: 10.1038/s41467-025-63548-2, https://www.nature.com/articles/s41467-025-63548-2
