The OxySense DO meter range uses world leading optical sensor technology to ensure precise, reliable measurements. This optical luminescent device is highly stable, abrasion-resistant, and reduces life costs and maintenance. With self-verification and automatic self-cleaning, the OxySense DO meter is easy to operate.
Its self-verification and self-cleaning features deliver low maintenance and high reliability. Optical DO sensors have largely replaced electrochemical DO sensors (Clark Cells) because they offer greater reliability and require less maintenance.
The OxySense optical DO sensor can be paired with different controllers, delivering consistent high performance results while offering varied display, communication, and control options.
Principle of Operation
The system has a blue light source which, when illuminated, excites or activates the sensing element, the lumiphore. The activated lumiphore emits red light with an intensity that is inversely proportional to the amount of oxygen dissolved in the water.
A measurable time delay exists between the peak emission of blue light and the peak response of fluoresced red light, and this delay is inversely related to the concentration of dissolved oxygen.
This time delay is considered to be a phase shift between the wave patterns of fluoresced red light and the incident blue light. The DO meter measures this as a mg/l or ppm reading of dissolved oxygen.
The system shows high resistance to abrasion and is more stable than conventional electrochemical devices.
By combining advanced electronics with traditional sensors, the OxySense DO meter delivers superior reliability, flexibility, and accuracy, compared to competing devices, while also offering excellent value for money.
Key Benefits
The OxySense DO meter can be used in oxidation ditches and aeration lanes to control the air blowers. Coupling a reliable dissolved oxygen sensor with Pi’s electronics delivers up to 24 months between maintenance and calibration, resulting in one of the most advanced DO meters available today.
The self-verification option lets the system monitor its own functionality daily and call for calibration when needed.
- No chemicals or moving components
- Down to zero maintenance
- Rugged online optical DO meter
- Best suited for all Dissolved Oxygen applications
- Data-logging and remote internet access with text alarms
- Optional self-cleaning and self-verification system
- No initial calibration needed
- Stable and reliable – exceptional process control
- Proven reliability
- Up to 24 months between maintenance
- Range of process control PID options – reducing labor costs
- Better performance than competitors’ dissolved oxygen sensors
- Up to 24 months between calibration events
- Optional AutoFlush Compressor
Applications
Online measurement of dissolved oxygen in an oxidation ditch or aeration lane requires a DO meter and is essential for efficient plant operation. Since aeration with blowers often accounts for around 50% of a wastewater plant’s operating costs, any drift or measurement inaccuracy can lead to significant financial losses.
To use DO meters to control blowers, the system must be drift-free, reliable, and low-maintenance, since maintaining DO meters and dissolved oxygen analyzers is expensive.
The industry’s shift from amperometric Clark cells to optical sensors has greatly improved DO monitoring in aeration lanes. However, not all optical DO meters perform equally - many, including leading brands, still suffer from drift over time and demand high levels of maintenance.
Pi has designed equipment that requires zero maintenance.
- Extremely low drift
- Lumiphore life of two years plus
- Alarms for dirty sensor, lack of response, sensor failure, etc.
- Autoclean – water or air
- Zero operator intervention for up to two years
- No initial calibration required
A clinical study in the UK installed an OxySense DO meter on an aeration lane and found the system required no maintenance, including calibration, for over 12 months while maintaining accuracy.
Sensor
The OxySense has been developed for dipping into oxidation ditches or aeration lanes. It has a self-cleaning feature and is completely waterproof.
Options
Autoflush
The OxySense can be configured to clean itself automatically at pre-defined intervals, without manual intervention. This feature allows deployment in applications where solids are likely to build up in samples, such as pulp and paper, food preparation, and other applications.
Multi-Sensor systems
The complete range of OxySense meters can be integrated with various sensors such as pH or chlorine.
