Quantum sensors for navigation use the physics of atomic superposition and interference to measure motion with extraordinary precision. These devices target a real problem: GPS signals fail underground, undersea, and in contested environments where jamming or spoofing corrupts satellite data. Researchers are building quantum accelerometers, gyroscopes, and magnetometers that operate independently of satellites and provide a path toward resilient positioning.
Global navigation satellite systems rely on weak radio signals broadcast from orbit, and these signals are easy to disrupt with inexpensive jammers or spoofing devices. Classical inertial navigation systems avoid this dependency but drift over time because they integrate noisy acceleration and rotation data without any external correction. Quantum sensors offer a third option. They measure inertial quantities directly from atomic behavior, producing signals with lower long-term drift than mechanical or optical alternatives.1,2
Maritime and aerospace operators face this problem acutely because underwater and remote environments block satellite reception entirely. A recent IEEE report on maritime quantum navigation found that quantum-enhanced sensors, paired with atomic clocks, could extend reliable navigation periods well beyond what classical inertial systems achieve alone. This makes quantum sensing attractive for submarines, aircraft, and spacecraft operating far from ground infrastructure.3
Cold Atom Interferometry Explained
Cold atom sensors trap and cool a cloud of atoms to near absolute zero, then split each atom into a quantum superposition of two motional states using precise laser pulses. As the atoms follow slightly different paths through space, differences in gravity, acceleration, or rotation alter the phase of each path. Recombining the paths creates an interference pattern, and the resulting phase shift indicates the inertial quantity being measured.1
This approach delivers accuracy that rivals or exceeds high-grade commercial gyroscopes and accelerometers over long measurement periods. Cold atom gyroscopes have shown angular errors of about 10-9 radians over 10,000 seconds, a stability level that outperforms many fiber-optic navigation gyroscopes. Accelerometers built on the same principle achieve precision near 10-8 m/s2, comparable to instruments used in aviation-grade inertial systems.1
Bose-Einstein condensates push this precision further by cooling atoms into a single quantum state where thermal motion nearly disappears. This tighter control reduces wavefront distortion and improves detection accuracy by providing better spatial resolution during imaging.2
Engineers have demonstrated six-axis measurement schemes using a single condensate source split into multiple interferometers, thereby capturing both acceleration and rotation from a single atomic cloud.2
Quantum Magnetometers and Gravity Mapping
Magnetic navigation provides an alternative method for positioning without GPS. Optically pumped magnetometers and vector sensors, such as fluxgates, measure the surrounding magnetic field and compare it to a pre-existing magnetic map of the region.4
Saving this for later? Download a PDF here.
A collaborative trial was conducted by NATO's Centre for Maritime Research and Experimentation, the University of Pisa, and TNO to evaluate this Magnetic Aided Inertial Navigation System. The resulting field data were utilized to correct the drift accumulated by conventional inertial sensors.4
Quantum gravimeters and gravity gradiometers follow a similar logic, matching measured gravitational variations to known terrain features. A recent report from the Quantum Economic Development Consortium identified magnetic navigation as one of the highest feasibility use cases for quantum sensing.5
This method yields positioning information that cannot be jammed or spoofed the way satellite signals can. The report also highlighted precision timing for space networks and satellite orientation as parallel opportunities for the same underlying sensor class.5
Combining Quantum and Classical Systems
Pure quantum navigation faces a bandwidth limitation because atom interferometers operate at low measurement rates, often just a few Hz, compared to the several hundred Hz achievable by conventional inertial sensors.1,2
During the cooling and trapping cycle, the sensor produces no usable signal, creating dead time that a moving vehicle cannot afford. Engineers solve this by pairing a classical inertial measurement unit for continuous high-rate output with the quantum sensor, which serves as a periodic correction reference.1,2
An extended Kalman filter is used to handle a combination of measurements. The classical unit predicts how much the phase of the atom interferometer should change. When a quantum measurement is received, the filter uses any differences to fix biases in the classical sensor. Simulated driving trajectories using this method showed velocity accuracy improved by roughly two orders of magnitude during stationary phases. However, when the vehicle started accelerating, the accuracy gains dropped to around 40 times.2
This hybrid design solves a second problem, too. Quantum gyroscopes have difficulty measuring rotation around multiple axes with a single low-bandwidth measurement. This limitation can create confusion about heading over time. Continuous classical data fills these gaps, letting the atom interferometer contribute its superior long-term stability without needing to track every rapid maneuver on its own.2
Current Engineering Challenges
The biggest challenges to widespread adoption of cold atom systems are their size, weight, and power requirements. Currently, these systems require vacuum chambers, laser arrays, and magnetic shielding, making them significantly bulkier than microelectromechanical sensors used in phones and vehicles. Photonic integrated circuits are seen as one path toward shrinking these components while maintaining performance, though this technology remains largely in the early research stages.5
Dynamic range presents another constraint. Atom trajectories inside an interferometer must stay within a narrow window of acceleration and rotation, or the atomic paths fail to recombine correctly, and the measurement is lost entirely. This limits current devices to platforms with predictable, gentle motion profiles, such as aircraft in level flight, rather than vehicles undergoing sharp maneuvers.2
Engineering teams working on high-precision quantum navigation also cite degradation of measurement accuracy in dynamic environments as a persistent bottleneck that slows practical deployment. Progress continues through improved laser sequencing, multiple atom species operating in parallel, and better isolation from vibration, but translating laboratory results into ruggedized field systems takes considerable time.6
Where Is This Technology Headed?
Near-term applications favor platforms that can absorb current size and weight demands, including ships, aircraft, and spacecraft. As photonic integration matures and hybrid filtering algorithms improve, smaller vehicles and eventually handheld devices may gain access to quantum-grade positioning.3,5
The core appeal stays consistent across every application, positioning information that no external signal can jam, spoof, or block, drawn instead from the fundamental physics of atoms in motion.3,5
References and Further Reading
- Wright, M. J. et al. (2022). Cold atom inertial sensors for navigation applications. Frontiers in Physics, 10, 994459. DOI:10.3389/fphy.2022.994459. https://www.frontiersin.org/journals/physics/articles/10.3389/fphy.2022.994459/full
- M. Gersemann, A. et al. (2025). Developments for quantum inertial navigation systems employing Bose–Einstein condensates. Appl. Phys. Rev., 12 (3): 031306. DOI:10.1063/5.0250666. https://pubs.aip.org/aip/apr/article/12/3/031306/3351228/Developments-for-quantum-inertial-navigation
- O. Sambataro et al. (2025). Current Trends and Advances in Quantum Navigation for Maritime Applications: A Comprehensive Review. IEEE Journal of Oceanic Engineering, vol. 50, no. 3, pp. 2101-2134. DOI:10.1109/JOE.2025.3538941. https://ieeexplore.ieee.org/abstract/document/10965754
- Jukic, M. et al. (2024). Quantum sensing for magnetic-aided navigation in GPS-denied environments. Proc. SPIE 13202, Quantum Technologies for Defence and Security, 1320204. DOI:10.1117/12.3034019. https://www.spiedigitallibrary.org/conference-proceedings-of-spie/13202/1320204/Quantum-sensing-for-magnetic-aided-navigation-in-GPS-denied-environments/10.1117/12.3034019.short
- Quantum Sensing for Position, Navigation and Timing Use Cases. (2024). QED-C. https://quantumconsortium.org/publication/pnt2024/
- QIU, Jinfeng. et al. (2025). Research Progress on High-precision Navigation Technology Based on Quantum Sensors. Navigation and Control, 24(5): 14-26,45. DOI:10.3969/j.issn.1674-5558.2025.05.002. https://gthjjs.spacejournal.cn/en/article/id/a5dd05bb-ba82-4ca0-9fe9-cec9d1fc1a02
