Strain Gauge-based Load Cells Go Digital

Leading weighing technology expert, HBM has launched a new load cell conditioner - DSE-HIE, which allows any strain gauge-based load cell to operate in a modern, industrial Ethernet system.

Developed with highly dynamic and automated weighing applications in mind, DSE-HIE is also European Hygienic Engineering & Design Group (EHEDG) compliant, making it ideal for applications with stringent hygiene and cleanliness standards, such as food and beverages, pharmaceutical or chemical process industries.

The device’s stainless-steel casing and IP67/68/69K degree of protection, allows it to be washed quickly and thoroughly, by high-pressure cleaners or by clean-in-place (CIP) systems, thus reducing downtime - and the risk of cross-contamination.

The output of the new weighing electronics is in line with common industrial Ethernet protocols - PROFINET RT/IRT and EtherCAT (in preparation). Parameterization and acquisition of measured values is possible via an integrated web interface using TCP/IP - or directly via the PLC.

Maximum output for retrofitting and new systems is guaranteed with 10,000e (0.01%FS) and 2,000 measured values per second. It has integrated filters for precise weighing applications, such as industrial automation or weighing application in rough conditions - and moving parts or vehicles.

HBM also offers easy-to-clean, EHEDG-compliant load cells to complete the hygienic measurement chain.

More information about these products, is available on HBM’s website: https://www.hbm.com/DSE
