Nov 10 2010
Contelec has devised innovative ultra-small rotary angle sensors featuring robustness, highly condensed dimensions, accuracy, fine-resolution capability and standard quality combined in a single system.
Miaiaure rotary sensors
The devise is equipped with tiny rotary sensing units having 9mm body diameter, complete and enhanced series including a calibration range in the order of 360º and sensing units with unique output features and switching operations. Apart from these characteristics, contact-less miniature angle sensing units are also accessible for integrating the permanent magnets to the revolving object by the user
This system performs mechanical coupling with the user's axis and the calibration unit, eliminating the occurrence of any sort of wear experienced by radially and axially acting forces. These tiny rotary sensors with a maximum of 14-bit resolution capacity and ingress protection class IP68 allow its extended use.
Source: http://www.contelec.com
