KiTorq - Cost-effective Torque Sensor Instrument by Kistler

The Kistler KiTorq torque sensor system is now available with Profibus, Profinet CANopen, Ethercat and EthernetIP interfaces in addition to the analog/frequency, USB and RS-232 interfaces.

The new stator is fully compatible with all KiTorq type 4550A rotors. The new communication options allow the KiTorq system to be integrated directly into the user’s test environment through the fieldbus interfaces.

This saves time during installation and eliminates the cost of additional equipment to convert measured data making the new KiTorq stator exceptionally cost effective for test stand design, installation and operation in applications for electric motor, internal combustion engine, transmissions, pump and compressor testing.

The new stator can be used with any KiTorq rotor of the same speed rating and will automatically recognise the rotor measuring range.

KiTorq system by Kistler.

With rotors available with seven measuring ranges from 100 to 5,000 Nm, hardware investment is minimised as one stator may be used with rotors of differing ranges for different applications.

Installation is simplified by the contactless, digital telemetry that eliminates the need for an antenna ring whilst maintaining the excellent signal bandwidth of 10 kHz and accuracy of better than 0.05% of range. A speed measurement of 60 pulses per revolution is integrated in the standard system.

Kistler Group

The Swiss-based Kistler Group is a leading global supplier of dynamic measurement technology for pressure, force, torque and acceleration. Kistler’s technology is used to analyse physical processes, control industrial processes and optimize product quality.

Kistler has a full range of sensors, electronics and systems for engine development, vehicle technology, assembly technology, plastic and metal processing as well as for biomechanics.

The Group maintains its global presence through 28 sales and manufacturing companies, with tech centres on all continents and more than 30 agencies, enabling the Group to maintain local contact with customers and offer individualized application support.

The Kistler Group employs 1,200 people and generated revenues of CHF 279 million (GBP 193M) in 2012.
