tecsis LP now offers the Model XLDR, a robust compression load cell specifically designed to measure the load on oil well ‘sucker rod’ pumping systems.
These bonded foil strain gage load cells provide 0.50% combined accuracy (FSO) and are engineered for severe outdoor use with sealed construction and built-in lightning protection. Our proprietary body design matches the industry-standard mounting configuration and will seamlessly integrate into new or existing pump-off control operations.
The Model XLDR polished rod load cell is fatigue rated and available in ranges from 30,000 to 50,000 lbf with a 200% safe overload capacity. Standard output is 2 mV/V, with CSA approved 4-20mA output available as an option. The operating temperature is -40° to 175°F, compensated from 0° to 150°F.
the Model XLDR, a robust compression load cell.
Available options include high resistance bridges, a variety of mating connector and cable assemblies, and spherical mounting washers. Model XLDR is available now from tecsis LP, priced from $497.
Contact tecsis at 614-430-0683 or click for pricing. tecsis LP, 771-F Dearborn Park Lane, Worthington, Ohio 43085 USA. Email: [email protected] Web: www.tecsis.us. Made in USA. tecsis LP is an ISO 9001:2008 Certified company.
