The BELLMINI: A Portable Gas Detector

Need more information?

Let us help you with your inquiries, brochures and pricing requirements

Request A Quote
Download PDF Copy

The GDI BELLMINI is a single-gas portable detector, exclusive to IGD, offering cutting-edge personal protection in a compact and ergonomic design. The BELLMINI ensures precise, instantaneous target gas detection with its LCD screen, user-friendly one-button operation, and sensor options for up to 18 gases.

The ultra-low power design guarantees a two-year battery life, and the sturdy weather and dustproof construction provides ingress protection. Clear visual, auditory, and vibrating alarms will help you stay vigilant against threats.

Customers can also manage real-time data using the Internet of Things and gather sophisticated data logs using the BELLCONNECT^™ App. Upgrade the personal safety of the team by using the most cutting-edge portable gas detector available today.

Product Type

Single Gas Portable Detector

Gas Type

Options Available

O₂ (oxygen): 0.1 % to 30 % VOL
0.1-30 % Oxygen LF (O₂) VOL
H₂S (hydrogen sulfide): 0.1–200 ppm
CO (carbon monoxide): 1–1000 parts per million
Ammonia (NH₃): 1–100 ppm
Hydrogen Cyanide (HCN): 1–50 ppm
H₂ (hydrogen): 1-1000 ppm

Future Options Coming 2025

SO₂ (Sulfur Dioxide)
CL₂(Chlorine)
Ethylene Oxide (ETO)
Nitric Oxide (NO)
Extended Ammonia Range: 1–1000 ppm (NH₃)
HCL, or Hydrogen Chloride
Ozone (O₃)
Nitrogen Dioxide (NO₂)
PH₃ (Phosphorus)

Key Features

Portable gas detector with targeted single-gas monitoring.
Sensor options available for 18 different gases.
Control via phone or tablet using the BELLCONNECT^™ App.
Clear audible, visual, and vibrating alarms.
Customisable alarm levels.
Ergonomic design with a robust, intrinsically safe build.
Two-year battery life with no replacements needed.
Log up to 200 events for easy tracking and review.
Simple, intuitive one-button operation.
IP68-rated: dustproof and waterproof for harsh environments.

Description

Advanced Single-Gas Monitoring: Featuring high-performance sensor technology and advanced signal processing, the BELLMINI delivers accurate, reliable low-level detection, with sensor options for 18 different gases.
BELLCONNECT^™ App and Remote Monitoring: The Bluetooth app provides full connectivity and control of your device. You can customise alarm levels, perform bump tests and calibrations, and access data logs via the app. Remote monitoring allows for precise location tracking and real-time readings of all GDI portable gas detectors on your network via a laptop.
Data Logging and Event Logging: With advanced data logging and the capacity to record and manage up to 300 event logs, the BELLMINI offers complete control and detailed data insights. All data and event logs can be accessed and downloaded through the BELLCONNECT^™ App.
Clear Alerts: The BELLMINI features LED lights for visual alarms, loud audible alerts, and a vibrating setting to ensure immediate notification—even in noisy, high-activity environments.
Robust, Pocket-Sized Build: Built for the harshest conditions, the BELLMINI has an IP68 dust- and waterproof rating. Its rugged, ergonomic design is compact yet durable enough for demanding environments.
User-Friendly Design: Lightweight enough for continuous wear, the BELLMINI offers intuitive one-button operation and a clear LCD screen for easy navigation and readings.
‘SAFE’ Settings: Since the BELLMINI measures at the ppm level, it defaults to displaying “SAFE” when only negligible or trace levels of the target gas are detected. This prevents unnecessary alerts and interruptions. The setting can be adjusted through the app as needed.
